Product Description:
Technics of Equipment
The equipment is designed for sheeting paper in various industries
such as paper mills and printing houses. The process involves
unwinding, cutting, conveying, and collecting.
Standard Configuration
The equipment comes with a middle slitting and waste edge
collecting system, which includes:
- Style: Adjustable slitting knife and exhaust tube for waste edge on both
sides
- Top slitter: Can be adjusted up or down and the slitting width can be manually
adjusted.
- Bottom slitter: Has a fixed position, but the slitting width can be adjusted
manually.
- Fan: Equipped with a driven motor.
- Type-Y collecting pipe: Used for collecting waste edge.
High Precision Single Rotary Sheet Cutter
This equipment also features a high precision single rotary sheet
cutter, which includes:
- Top Tool Apron: Utilizes advanced cutting technology to reduce noise and load, and
extend the life of the knife.
- Bottom Tool Apron: Made with stable processing techniques for maximum stability.
- Main Driving Roller: Has a grainy surface and is controlled by air pressure to grip the
paper and provide powerful driving force.
- Double Rolling Bands: Can feed 2 papers at once, reducing cutting errors and ensuring
stable paper feeding.
Features:
Auto-Squareness Adjustment System
Type:
Efficiently fixed Tool Apron designed according to British
standards.
Control Way:
Automatically adjusts the squareness of paper based on calibration
displayed on the Touching screen.
Paper Conveyer System
Type:
Multi-stage, horizontal conveying system for efficient counting and
piling, equipped with high efficiency dust collecting equipment.
The first conveying stage:
Quickly separates cutting paper.
The second conveying stage:
Slowly conveys paper in a tile-like shape, with single or linked
control for precision.
Technical Parameters:
| Product Attribute | Value |
|---|
| Product Name | Used Roll Paper Sheet Cutter Machine |
| Type | Roll Paper Sheet Cutter |
| Condition | Used |
| Number of Rolls Cutting | 2 Rolls |
| Finished Sheet Length | Min. 450mm - Max. 1650mm |
| Finished Width | Max. 1400mm (55 inches) |
| Max. Speed of Cutting | 300 cuts/min |
| Max. Cutting Speed | 300m/min |
| Requirement of Air Pressure | 0.8MPa |
| Color | White |
| Voltage | AC380V/220Vx50Hz |
Applications:
Used Roll Paper Sheet Cutter Machine
Brand Name: CHM
Model Number: CHM-1400 II
Place of Origin: CHINA
The Used Roll Paper Sheet Cutter Machine, manufactured by CHM, is a
high-quality and efficient Paper Processing Machinery designed to
cater to the needs of various industries. The CHM-1400 II model is
the latest addition to the CHM family, known for its precision and
reliability.
The machine is primarily used for converting large rolls of paper
into manageable sheets, making it an essential tool for industries
such as printing, packaging, and paper manufacturing. Its advanced
technology and superior cutting capabilities make it a preferred
choice for Paper Processing Machinery.
The Roll To Sheet Paper Sheeting Machine has a finished width of
maximum 1400mm (55"), making it suitable for cutting various sizes
of paper sheets. The machine operates at a maximum cutting speed of
300m/min, with a cutting speed of 300 cuts per minute, ensuring
quick and efficient production.
One of the key features of this machine is its white color, which
not only adds to its aesthetic appeal but also ensures that the
machine remains clean and free from dust and debris. This is
crucial for maintaining the quality of the paper sheets produced.
As a leading Paper Processing Machinery Manufacturer, CHM has
incorporated advanced technology and innovative designs in the
CHM-1400 II model. The machine is equipped with a user-friendly
interface, making it easy to operate and monitor. It also has
safety features in place to prevent accidents and promote a safe
working environment.
The Used Roll Paper Sheet Cutter Machine is suitable for various
applications such as cutting paper sheets for printing flyers,
brochures, and labels, as well as for packaging and labeling
products. Its versatility and efficiency make it an ideal choice
for businesses looking to increase their production and improve
their overall efficiency.
Overall, the CHM-1400 II model is a top-of-the-line Roll Paper
Sheet Cutter Machine that offers precision, speed, and reliability.
As a trusted brand in the industry, CHM ensures that their machines
are of the highest quality, making them a preferred choice among
businesses worldwide.
FAQ:
- Q: What is the brand name of this product?
- A: The brand name of this product is CHM.
- Q: What is the model number of this product?
- A: The model number of this product is CHM-1400 II.
- Q: Where is this product manufactured?
- A: This product is manufactured in China.
- Q: What is the maximum width of the roll paper that can be cut by
this machine?
- A: The maximum width of the roll paper that can be cut by this
machine is 1400mm.
- Q: Does this machine have an automatic paper feeding system?
- A: Yes, this machine is equipped with an automatic paper feeding
system.
