MY-1320X/1500X/1680X Bottom Suction Nozzle Lead Edge Feeding
Automatic Die Cutting & Creasing Machine
Main Features
1. Equipped with pneumatic clutch and pneumatic locking plate.
2. Lead edge feeding paper. The high-speed and high precision paper
feeding device can transmit all kinds of corrugated paper whenever
how the quality of paper is. Equipped with light-adjusted device
and has suitable ability.
3. Automatic adjusting paper feeding, paper collecting and paper
aligning.
4. Automatic gripper type equipped the tooth row, open bite
adjustable, under the help of paper, cardboard can run smoothly.
Automatic suction suck about using leading edge of paper, tooth row
gripper-style, curved cardboard and tissue paper can also be passed
no scratches.
5. Pneumatic take samples when machine working, can check the die
cutting effect at any time.
6. Dusting air guns, can effectively remove the template, and dust
inside the device.
7. Automatic lubricating can add lubricating oil on the chain gear
according to time, extended the working life of machine
8. Using alarm bells agencies in warning tone when the device is
turned to raise safety warning.
9. Equipped with a precision of detection (Taiwan Riko) fiber optic
switch, the paper is in place to detect and avoid paper waste.
Products Description
| PARAMETER |
| Model | MY-1320X | MY-1500X | MY-1680X |
| Max. sheet size | 1320X960(mm) | 1500X1105(mm) | 1680X1235(mm) |
| Min. sheet size | 450X465(mm) | 500X465(mm) | 580X500(mm) |
| Max. die cutting size | 1300X940(mm) | 1480X1090(mm) | 1660X1220(mm) |
| Max.cutting speed | 6000s/h | 5500s/h | 5000s/h |
| Die cutting precision | ±0.15mm | ±0.18mm | ±0.2mm |
| Sheet thickness | 200-2000g/㎡(Cardboard) ≤10mm(corrugated board) | 250-2500g/㎡(Cardboard) ≤10mm(corrugated board) | 250-2500g/㎡(Cardboard) ≤10mm(corrugated board) |
| Max.pressure | 380T | 400T | 480T |
| Total power | 25kw | 25kw | 26kw |
| Net weight | 20T | 22T | 24T |
| Overall dimension | 6750X4600X2260mm | 7600X5100X2260mm | 8000X5450X2500mm |
| Air requirements | 0.8Mpa,>0.36m³/min | 0.8Mpa,>0.36m³/min | 0.8Mpa,>0.36m³/min |
Advantage
- Die-cutting unit eliminated castings wallboard due to casting
wallboard has small pull, large deformation and without limitation,
instead it uses steel wallboards like Japan. To increase pulling
force is to increase pressure, and it is strong and durable,
changeless form.
- Automatic pressure control make the machine achieve new successes.
This added functions, make it become the digital equipment,
handling fast, convenient to use.
- Taiwan high-pressure oil pump, use crush type for lubrication,
reducing parts attrition and increasing oil temperature cooler to
lubricant for cooling, on the main chain for regular lubrication,
improve equipment efficiency.
- It has novel drive mechanism, execute high-speed die-cutting, high
accuracy of swinging rod platform and improve the pad speed (almost
don't need mat), we should know, a lot of manufacturers exist
pressure uneven problem.
- Pneumatic locking plate device has firmer upper frame, saving time.
Our company produces the die-cutting machine simultaneously to
nether frame around for air lock, leading to strong accuracy, speed
fast. All other manufacturers are just using screw fastening.
FAQ
1. Q: Are you trading company or manufacturer?
A: We are manufacturer, and also provide the business solution to
all the friends.
2. Q: What is your delivery time ?
A: Normal delivery time is 30-55working days beside less stock
model after received your deposit .
3. Q: Can you help us to buy other goods?
A: Sure of that, it is our honor to work for you, and control the
goods quality.
4. Q: How was your machine warranty ?
A: our all machines has one and half year (18monthes) guarantee.
Beside guarantee we will supply
cost spare parts and free maintenance knowledge .
5. Q: How can you do after sales service ?
A: beside the quality guarantee, our company also regards the after
sales service, using a full
arrange of service to solve the problems of clients. We supply
multiple channels of service by 7x24
hours on phone / on site technical support / on site service /
preventive maintenance also training
again.
6. Q: What’s your payment terms ?
A: 30% deposit by TT , 70 % balance before shipping by TT or at
sight L/C, western union /cash are also
accepted for us .
