    Paper Semi Automatic Die Cutting Machine Three Stripping Unite Box Die Cutting Machine

    Ask Lasest Price
    Brand Name : JIGUO
    Model Number : BMY-1500P
    Certification : CE
    Price : $160000to $170000/1 Set
    Payment Terms : L/C, T/T
    Supply Ability : 50 set
    Delivery Time : 45 days
    • Product Details
    • Company Profile

    Paper Semi Automatic Die Cutting Machine Three Stripping Unite Box Die Cutting Machine

    BMY-1500A Three Stripping Fram Structure Semi-automatic Die Cutting And Stripping Machine


    Detail Product Description


    1.Semi-automatic die-cutting and stripping machine It suits for 250-2500g/m²

    cardboard, corrugated paper below 8mm.


    2.The machine includes 4 parts:feeder,paper feed section,main motor and delivery section.

    And it can finish feeding,die cutting,stripping and collecting work cycle automatically.


    3.The feeder suction and conveyor ESD system can transport the plastic sheet smoothly.

    It adopts to import heated galvanic and temperature control system,which adjust 12 stages

    independently,and it also ensure the temperature stability,that solve the white edge of

    die cutting plastic material and burr phenomenon.


    4.The machine is equipped with automatic lubrication system.And the swing rod and

    copper tile are all reworked by hand .we scrap the surface and make it full of criss-cross

    scrath. the groove hold more oil that can ensure smooth going of the operation,

    and the precision of the pattern.

    Paper Semi Automatic Die Cutting Machine Three Stripping Unite Box Die Cutting Machine


    Products Description​

    PARAMETER
    ModelBMY-1500P
    Max. sheet size1500X1105(mm)
    Min. sheet size500X420(mm)
    Max. die cutting size1480X1090(mm)
    Max.cutting speed5000s/h
    Sheet thickness

    250-2500g/㎡(Card paper)

    <8mm(corrugated paper)

    Max.pressure400T
    Total power15kw
    Net weight18T
    Overall dimension7650X4850X2260mm
    Air requirements0.8Mpa,>0.36m³/min

    Local Description

    Paper Semi Automatic Die Cutting Machine Three Stripping Unite Box Die Cutting Machine

    Paper Semi Automatic Die Cutting Machine Three Stripping Unite Box Die Cutting Machine


    Paper Semi Automatic Die Cutting Machine Three Stripping Unite Box Die Cutting Machine


    Paper Semi Automatic Die Cutting Machine Three Stripping Unite Box Die Cutting Machine

    FAQ

    1. Q: Are you trading company or manufacturer?

    A: We are manufacturer, and also provide the business solution to all the friends.

    2. Q: What is your delivery time ?

    A: Normal delivery time is 30-55working days beside less stock model after received your deposit .

    3. Q: Can you help us to buy other goods?

    A: Sure of that, it is our honor to work for you, and control the goods quality.

    4. Q: How was your machine warranty ?

    A: Our all machines has one and half year (18mouthes) guarantee. Beside guarantee we will supply

    cost spare parts and free maintenance knowledge .

    5. Q: How can you do after sales service ?

    A: Beside the quality guarantee, our company also regards the after sales service, using a full

    arrange of service to solve the problems of clients. We supply multiple channels of service by 7x24
    hours on phone / on site technical support / on site service / preventive maintenance also training
    again.

    6. Q: What’s your payment terms ?

    A: 30% deposit by TT , 70 % balance before shipping by TT or at sight L/C, western union /cash are also

    accepted for us .
