    580×500mm Paper Semi Automatic Die Cutting Machine Flat Bed BMY 1680A

    Ask Lasest Price
    Brand Name : JIGUO
    Model Number : BMY-1680A
    Certification : CE
    Price : $50,000 to $100,000/1 Set
    Payment Terms : L/C, T/T
    Supply Ability : 50 set
    Delivery Time : 45 days
    • Product Details
    • Company Profile

    580×500mm Paper Semi Automatic Die Cutting Machine Flat Bed BMY 1680A

    JIGUO Semi-Automatic Flat Bed Die Cutting Machine

    Machine introduction


    Semi-automatic die-cutting and creasing machine is the main equipment for making color boxes, paper boxes and paper labels.

    This machine is equipped with high-strength jaw opening teeth, integral swing leading, automatic derivation, high-precision spacer structure, pneumatic locking plate, pneumatic clutch, overload protection, automatic paper delivery, so that the paper feeding distance is shorter, the positioning accuracy is high, and the die-cutting is stable. , The paper is neatly received, and it can also be die-cutting without jaws.


    580×500mm Paper Semi Automatic Die Cutting Machine Flat Bed BMY 1680A

    Products Description​

    PARAMETER
    ModelBMY-1680A
    Max. sheet size1680X1235(mm)
    Min. sheet size580X500(mm)
    Max. die cutting size1660X1220(mm)
    Max.cutting speed4200s/h
    Sheet thickness

    200-2500g/㎡(Card paper)

    <8mm(corrugated paper)

    Max.pressure480T
    Total power16.5kw
    Net weight18T
    Overall dimension6750X5300X2500mm
    Air requirements0.8Mpa,>0.36m³/min

    System introduction


    580×500mm Paper Semi Automatic Die Cutting Machine Flat Bed BMY 1680A


    580×500mm Paper Semi Automatic Die Cutting Machine Flat Bed BMY 1680A 580×500mm Paper Semi Automatic Die Cutting Machine Flat Bed BMY 1680A

    580×500mm Paper Semi Automatic Die Cutting Machine Flat Bed BMY 1680A

    FAQ

    1. Q: Are you trading company or manufacturer?

    A: We are manufacturer, and also provide the business solution to all the friends.

    2. Q: What is your delivery time ?

    A: Normal delivery time is 30-55working days beside less stock model after received your deposit .

    3. Q: Can you help us to buy other goods?

    A: Sure of that, it is our honor to work for you, and control the goods quality.

    4. Q: How was your machine warranty ?

    A: Our all machines has one and half year (18mouthes) guarantee. Beside guarantee we will supply

    cost spare parts and free maintenance knowledge .

    5. Q: How can you do after sales service ?

    A: Beside the quality guarantee, our company also regards the after sales service, using a full

    arrange of service to solve the problems of clients. We supply multiple channels of service by 7x24
    hours on phone / on site technical support / on site service / preventive maintenance also training
    again.

    6. Q: What’s your payment terms ?

    A: 30% deposit by TT , 70 % balance before shipping by TT or at sight L/C, western union /cash are also

    accepted for us .
