TC-800AC Automatic Window Patching Machine Automatic Box Window
Patching Machine
TC-800AC window sticker is widely used for window or windowless
film for wine boxes and gift boxes. napkin box. Makeup case, etc.
It can also realize the functions of gluing, sticking film, cutting
film, and receiving paper before folding the box. The machine has
passed ISO9001 quality system certification, in line with European
CE safety standards.
The window sticking machine is suitable for sticking windows on
various carton boxes such as wine boxes, gift boxes, toilet boxes,
cosmetic boxes, children's toy boxes, milk boxes, etc. The machine
has the functions of automatic paper feeding, accurate positioning,
automatic gluing, automatic film cutting length, pressure
transmission input, etc. It has powerful functions and good
stability. The machine is easy to adjust and has high efficiency,
and it is an ideal equipment for laminating various carton boxes.
Specifications
| PARAMETER |
| Model | TC-800AC |
Max. Paper Size | 760×650mm |
| Min. Paper Size | 100×100mm |
Max. film Size | 460×460mm |
Min. film Size | 40×30mm |
Film Sheet Thickness | 0.03-0.4mm |
Max. Working Speed | 12000s/h ( Corner Cutting 4500s/h) |
Cardboard | 200-1200/m² |
Corrugated Paper | ≤ 5mm |
Total Power | 9Kw |
Total Weight | 2800kg |
Overall Dimensions | 4800×1405×1520mm |
Overall Dimensions(When the roller is pulled out) | 4800×2100×1520mm |
Local display
 | 1. Man-machine interface This machine uses a 7-inch touch screen display and a host computer
(PLC) to digitally adjust the film length and count. |
 | 2. Feeding
The paper feeding part is controlled by a servo motor, the paper
pile moves intermittently during the feeding process, the belt has
a long service life, and the paper products are processed to the
conveying part in a smooth and orderly manner. Great for cardboard
and corrugated paper. |
 | 3. Conveying Parts
The paper feeding part is equipped with four conveyor chains and
four push blocks, which can be adjusted according to the shape of
the paper. It is equipped with 4 photoelectric sensors to detect
paper arrival, counting, jam detection. |
 | 4. Gluing Parts
The gluing part adopts an adjustable part gluing structure, which
is easy to adjust according to the paper requirements and the
gluing position, saves the gluing amount, and the gluing part is
easy to pull out and clean. The gluing roller stops gluing when the
machine stops. And the conveying parts fall down automatically, and
it is not easy to print on the conveying belt by gluing. |
 | 5. Double gluing system
The upper roller is the cutting film roller with the two blade ,one
the upper blade, the other is the lower blade, finishing the
cutting of the film The below roller is the suction roller, the
film is patched on the suction roller Servo film adjustment |
 | 6. Paper Delivery parts
The patching products conveying to the paper delivery plate, finish
the paper accumulation and collection Paper delivery parts can
be adjust single. |
Application
FAQ
Q1: Are you a manufacturer or a trading company?
A: We have our own factory in Tangshan, Hebei Province.
Q2. What is the machine warranty?
A: One year. After the warranty, we still provide technical support
to buyer at low cost.
Q3. What is the production time while placing order?
A: Normally about 20-30 days.
Q4. What is the delivery time?
A: 35-50days after deposit.
Q5. Can your company handle shipping for customers?
A: Yes, just give us destination sea port or container yard.
Q6. Does the packing strong?
A: Yes. Adopts moisture-proof and shock-proof packaging which is
suitable for long-distance road transportation and various types of
weather conditions. A full set of maintenance and operation manuals
is included.
Q7. How about the machine installation and training?
A: 1) We provide training in our factory for free; 2) We can send
technicians (engineers) to your factory for installation and
training. You shall pay round trip air fare and accommodations,
plus each technician charges USD100/per day.
Q8. Do you have machines in stock?
A: For standard model, we have a large quantity in stock.For
special model,we need 20-30 days to produce for you.
Q9. How can you assure the machines' quality?
A: Each machine will be test running at least 24 hours before
delivery to assure the quality. And during the warranty, we will
give spare parts for free if machine has any problem.
Q10. Do you inspect machines or test running before packing?
A: Of course we do. We have QC department to debug the machine
before packing. If you want to use specific material to do the test
running, you need to pay for the cost of the material
Q11. What's the payment term?
A: T/T 30% in advance, the balance shall be paid before delivery.
Also accept payment by West Union or L/C at sight.
Q12. Do you accept factory visiting?
A: Warmly welcome for your visiting.
Q13. How many years are you in printing field?
A: JIGUO factory is more than 20years.
