    High Speed BOPP Film Laminator Machine Automatic Thermal 1080x1000mm Sheet

    Ask Lasest Price
    Brand Name : JIGUO
    Model Number : FMZ-1080AN
    Certification : CE, ISO9001
    Price : USD50000-70000/set
    Payment Terms : L/C, T/T
    Supply Ability : 50 sets per month
    Delivery Time : 20days
    • Product Details
    • Company Profile

    High Speed BOPP Film Laminator Machine Automatic Thermal 1080x1000mm Sheet

    JIGUO FMZ-1080AN Model Automatic BOPP Thermal Film Laminator Machine


    This model is one of most advanced type of BOPP thermal film laminator machine, adpots the latest world technology, with our factory 20 years manufacturing experience, it is high precision and reliable working machine, so it is most ideal film finishing machine for printing house or packaging converting company.


    Features:

    1.Automatic paper feeder with oil-free vacuum pump to ensure the automatic paper feeding.

    2.Man-machine interface system: color touch screen, easy for operation; it realizes automatic operation after directly data input for paper size, overlap length and working speed, working status can be tracked via the screen.

    3.Automatic paper feeding system equipped with photocell detector and machine automatic stops to self- protection while short of paper, dual paper or paper breaks.

    4.Conveying table with air aspirator and front guide to ensure paper conveying and overlap to be stable and neat, and improve the lamination precision as well.

    5.Electro-magnetic heating system ensures lamination temperature constantly and makes it precise while for the lamination.

    6.Automatic hydraulic system ensures the stable pressure and the lamination quality.

    7.Air shaft convenient for film loading & unloading, and accurate for film release.

    8.Film shaft equipped with braking device to control the tension and speed of the film.

    9.The cutting unit and paper receiving unit can be easily moved away from the laminating unit, which makes the maintenance more convenient.

    10.Pneumatic cutting system realizes automatic paper cutting after paper size data input. With anti-vurve roller.

    11.The paper delivery stacker equipped for the sheet laminated paper


    Technical Specifications:


    ModelJIGUO FMZ-1080AN
    Max paper size1080 x 1000mm
    Min paper size350 x 295mm
    Working speed105m/min
    Total power60kw
    Overall dimensions9000 x 3000 x 3100mm
    Weight8500kg
