I:Product Description:
1. Suitable for laminating of cardboard and corrugated cardboard in
150-600 g/m2 .
2. The vacuum suction-type feeding system can lead the paper
accurately into the machine;cycle stacking planes in a state of
non-stop the next batch of paper stack well, so that more
efficient.
3. The machine operation is stable, surface paper with corrugated
paper joint very accurate. The corrugated paper never pull ahead,
surface paper's location is easy adjust.
4. The pressure conveyor adopt floating movable structure , total
length 5m , equipped with 28 paper pressing rollers , make the
cardboard uniform bearing strength in pressing process.
II:Features:
1.Feeder System
1)High precision high speed feeder , make the feeding smooth .
2)Strengthen type feeder device , the suction mouth angle can be
adjustable , according to different kinds of surface paper .
2.Electric system
1) Main electric appliances all adopt the imported famous brand .
2)PLC tracking technique , automatic fault detection .
3.Pressure adjustment system
1)Adjust the pressure in single side , to ensure the pressure is
same on both sides .
2)With pressure gauge display , can easily adjust when change the
paper size.
4.Pressure conveyor
1)Floating type pressure design , don’t need to adjust the pressure
of flatbed .
2)Heightening design , good for the smooth work of thick corrugated
cardboard .
III:Technical Parameters:
| Model | FMZ-1450 |
Max laminating size | 1450mm×1250mm |
Min laminating size | 400mm×400mm | | Economic speed | 0-100sheets/min | | Laminating precision | ±1.5mm | | Power | 12kw | | Size | 13.5m×2.15m×2.4m | | Weight | About 5.2t |
Bottom paper thickness | A/B/C/E flute, 3/4/5 layer , less than 12mm thickness |
Surface paper gram weight | 150-600 g/m2 |
|
IV:Applications:
The JIGUO FMZ-1450 Flute Laminator Machine, manufactured in CHINA,
is a high-quality product designed for various paper laminating
applications. With its CE certification, this machine is guaranteed
to meet international standards of quality and safety.
With a minimum order quantity of 1 and a supply ability of 20
units, the FMZ-1450 offers flexibility for both small-scale and
large-scale production needs. The machine's quick delivery time of
25 days and payment terms of T/T make it a convenient and reliable
choice for businesses looking to enhance their laminating
processes.
V:Customization:
Product Customization Services for the Flute Laminator Machine:
Brand Name: JIGUO
Model Number: FMZ-1450
Place of Origin: CHINA
Certification: CE
Minimum Order Quantity: 1
Delivery Time: 25
Payment Terms: T/T
Supply Ability: 20
Min Laminating Size: 400*400mm
Top Paper Thickness: 150-600g/m2
Rewinding Method: Automatic
Bottom paper thickness:A/B/C/E flute, 3/4/5 layer , less than 12mm
thickness
Keywords: Weight, Weight, Laminating precision
VI: Support and Services:
Our Flute Laminator Machine comes with comprehensive product
technical support and services to ensure optimal performance and
reliability. Our team of experienced technicians is available to
assist with any technical inquiries, troubleshooting, and
maintenance needs. We also offer training programs to help
operators maximize the efficiency of the machine.
VII:FAQ:
Q: What is the brand name of the Flute Laminator Machine?
A: The brand name is JIGUO.
Q: What is the model number of the Flute Laminator Machine?
A: The model number is FMZ-1450.
Q: Where is the Flute Laminator Machine manufactured?
A: The machine is manufactured in China.
Q: Does the Flute Laminator Machine come with any certifications?
A: Yes, it is certified with CE.
Q: What are the payment terms for purchasing the Flute Laminator
Machine?
A: The payment terms are T/T (Telegraphic Transfer).
